SSS10X152
Now 4x4 enthusiasts have a choice when it comes to the type of recovery shackle they use. Steel D-shackles are quickly being replaced with Sherpa's soft synthetic rope shackles. Rope shackles have many advantages over steel shackles and make for an ideal upgrade to any recovery kit.
Sherpa rope shackles are strong as they are made from high quality synthetic rope the same as what is spooled onto Sherpa winches. The 10mm (3/8") soft shackle uses genuine USA Spectra® fiber and achieve a rating of 15,900kg (35,000lb). Note: this is the shackles Minimum Breaking Strength (MBS) and actual testing often reveals even higher figures. Users can be confident these shackles will exceed the ratings of an equivalent size D-shackle.
Rope shackles are light weight and float in water. They will never rust. This makes soft shackles perfect for use in river crossing situations, it also means there is less mass to act as a projectile if a winch rope was to ever break. A heavy steel shackle can easily punch a hole through a vehicle and do serious injury if allowed to become a projectile. Whilst rope shackles still have some mass, they are much safer and don't store the same level of energy.
Rope shackles are simple to use and fast to set up. Carry them in your glove box or hang them off your belt. The soft shackle will not over tighten and are easy to loosen after a recovery.
Rope shackles can be wrapped around almost any surface or shape. Where a standard steel shackle might have bound, the rope shackle can quickly be manipulated to fit almost any situation.
Sherpa manufacture their soft rope shackles to be strong and also user friendly. Each shackle comes with a high quality protective sleeve ensuring years of use and performance. Each shackle is clearly labelled with its rating unlike inferior imitations.
Sherpa Soft Shackle Features:
Part Number | Rope Diameter | Loop Diameter | Total Length | Minimum Breaking Strain (MBS) |
---|---|---|---|---|
SSS10X152 | 10mm (3/8") | 152 mm | 600mm | 15,909 kg (35,000 lb) |
SSS16X600 | 16mm (5/8") | 600 mm | 1900mm | 32,400 kg (71,280 lb) |
Grunter Boat Winch Owner's Manual
Winch Dimensions:
'Mustang' 9,500Lb with 28m spool
'Brumby' 10,000Lb high speed winch
'Steed' 17,000Lb with 28m spool
'Steed' 17,000Lb with 45m spool
'Mule' 17,000Lb dual motor winch with 45m spool
'Stallion' 25,000Lb winch with 30m spool
'Grunter' boat trailer winches (Standard & HP Models)
'Grunter' Boat Trailer Winch Mounting Bracket
ATV Winch 4,500Lb Mounting Plate
Wiring Diagrams:
Dual Motor Winch Wiring Diagram
Winch Weights:
Winch Type | Other | 92ft (28m) Cable | 92ft (28m) Rope | 100ft (30m) Rope | 100ft (30m) Cable | 148ft (45m) Cable | 148ft (45m) Rope |
ATV Winch 4,500Lb | 15lb (7 kg) | X | X | X | X | X | X |
9,500Lb | X | 57lb (26 kg) | 42lb (19 kg) | X | X | X | X |
10,000Lb (High Speed) | X | X | 50lb (23 kg) | X | X | X | X |
12,000Lb | X | 66lb (30 kg) | 50lb (23 kg) | X | X | X | X |
17,000Lb Single Motor | X | 60lb (30 kg) | 50lb (23 kg) | X | X | 88lb (40 kg) | 57lb (26 kg) |
17,000Lb Dual Motor | X | X | X | X | X | 101lb (46 kg) | 71lb (32 kg) |
Tow Truck Winch 20,000Lb | X | 100lb (45 kg) | 66lb (30 kg) | X | X | X | X |
25,000Lb | X | X | X | 68lb (31 kg) | 104lb (47 kg) | X | X |
Cable Data:
Winch Type | Cable Type | Length | Cable Size |
Grunter Boat Trailer Winches (All models) |
Positive (Power) |
7m (~23ft) | 50mm² |
Negative (Earth) |
3m (~10ft) | 32mm² | |
Control Box Cables |
Various <1m (< ~3ft) From winch to control box only. | 25mm² | |
Grunter Cable Upgrade (Postive cable only) |
Positive (Power) |
10m (~32ft) | 50mm² |
4x4 Winches (All models) Mustang, Colt, Steed, Mule, Brumby, Stallion, Tow Truck winch models. |
Positive (Power) |
1.8m (~6ft) | 25mm² |
|
Negative (Earth) |
1.8m (~6ft) | 25mm² |
Control Box Cables |
Various <1m (< ~3ft) From winch to control box only. | 25mm² | |
4x4 Winch Cable Upgrade |
Positive (Power) |
3m (~10ft) | 25mm² |
Negative (Earth) |
3m (~10ft) | 25mm² | |
Big Air - Air Compressors (All models) |
Positive (Power) |
3m (~10ft) | 16mm² |
Negative (Earth) |
3m (~10ft) | 16mm² |
